12' Car & Equipment w/ 2-3500 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6312E, 6312M
- Overall Length: 16′
- Overall Width: 102″
- Axles: 2-3500 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 5-45 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 1,625 lbs.
- Deck Height: 21″
- Deck Length: 12′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 5″ Channel
- GVWR: 7,000
- Hitch Height: 18″
- Hitch Weight (Empty): 175 lbs.
- Jack: 2,000 lb A-Frame or Swivel
- Payload Capacity: 6,075 lbs.
- Ply: 6 Ply
- Slide in Ramps: 10″ x 40″
- Tires: 15″ C Range
14' Car & Equipment w/ 2-3500 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6314E, 6314M
- Overall Length: 18′
- Overall Width: 102″
- Axles: 2-3500 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 5-45 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 1,700 lbs.
- Deck Height: 21″
- Deck Length: 14′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 5″ Channel
- GVWR: 7,000 lbs
- Hitch Height: 18″
- Hitch Weight (Empty): 175 lbs.
- Jack: 2,000 lb A-Frame or Swivel
- Payload Capacity: 6,000 lbs.
- Ply: 6 Ply
- Slide in Ramps: 10″ x 40″
- Tires: 15″ C Range
16' Car & Equipment w/ 2-3500 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6316E, 6316M
- Overall Length: 20′
- Overall Width: 102″
- Axles: 2-3500 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 5-45 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 1,750 lbs.
- Deck Height: 21″
- Deck Length: 16′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 5″ Channel
- GVWR: 7,000 lbs
- Hitch Height: 18″
- Hitch Weight (Empty): 175 lbs.
- Jack: 2,000 lb A-Frame or Swivel
- Payload Capacity: 5,950 lbs.
- Ply: 6 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 15″ C Range
18' Car & Equipment w/ 2-3500 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6318E, 6318M
- Overall Length: 22′
- Overall Width: 102″
- Axles: 2-3500 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 5-45 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 1,800 lbs.
- Deck Height: 21″
- Deck Length: 18′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 5″ Channel
- GVWR: 7,000 lbs
- Hitch Height: 18″
- Hitch Weight (Empty): 300 lbs.
- Jack: 2,000 lb A-Frame or Swivel
- Payload Capacity: 5,900 lbs.
- Ply: 6 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 15″ C Range
20' Car & Equipment w/ 2-3500 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6320E, 6320M
- Overall Length: 24′
- Overall Width: 102″
- Axles: 2-3500 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 5-45 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 2,200 lbs.
- Deck Height: 21″
- Deck Length: 20′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 5″ Channel
- GVWR: 7,000 lbs.
- Hitch Height: 18″
- Hitch Weight (Empty): 300 lbs.
- Jack: 2,000 lb A-Frame or Swivel
- Payload Capacity: 5,500 lbs.
- Ply: 6 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 15″ C Range
16' Heavy Duty C&E w/ 2-5200 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6516E, 6516M
- Overall Length: 20′
- Overall Width: 102″
- Axles: 2-5200 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 6-55 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 1,980 lbs.
- Deck Height: 22″
- Deck Length: 16′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel
- GVWR: 9,900 lbs.
- Hitch Height: 19″
- Hitch Weight (Empty): 175 lbs.
- Jack: 7,000 lb Drop Leg
- Payload Capacity: 8,910 lbs.
- Ply: 8 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 15″ D Range
18' Heavy Duty C&E w/ 2-5200 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6518E, 6518M
- Overall Length: 22′
- Overall Width: 102″
- Axles: 2-5200 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 6-55 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 2,115 lbs.
- Deck Height: 22″
- Deck Length: 18′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel
- GVWR: 9,900 lbs.
- Hitch Height: 19″
- Hitch Weight (Empty): 300 lbs.
- Jack: 7,000 lb Drop Leg
- Payload Capacity: 8,775 lbs.
- Ply: 8 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 15″ D Range
20' Heavy Duty C&E w/ 2-5200 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 6520E, 6520M
- Overall Length: 24′
- Overall Width: 102″
- Axles: 2-5200 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 6-55 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 24″
- Curb Weight: 2,240 lbs.
- Deck Height: 22″
- Deck Length: 20′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel
- GVWR: 9,900 lbs.
- Hitch Height: 19″
- Hitch Weight (Empty): 300 lbs.
- Jack: 7,000 lb Drop Leg
- Payload Capacity: 8,650 lbs.
- Ply: 8 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 15″ D Range
16' Heavy Duty C&E w/ 2-7000 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 7716E, 7716M
- Overall Length: 20′
- Overall Width: 102″
- Axles: 2-7000 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 8-65 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 16″
- Curb Weight: 2,500 lbs.
- Deck Height: 26″
- Deck Length: 16′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel
- GVWR: 14,000 lbs.
- Hitch Height: 22″
- Hitch Weight (Empty): 175 lbs.
- Jack: 7,000 or 12,000 lb Drop Leg
- Payload Capacity: 12,900 lbs.
- Ply: 10 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 16″ E Range
18' Heavy Duty C&E w/ 2-7000 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 7718E, 7718M
- Overall Length: 22′
- Overall Width: 102″
- Axles: 2-7000 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 8-65 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 16″
- Curb Weight: 2,644 lbs.
- Deck Height: 26″
- Deck Length: 18′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel
- GVWR: 14,000 lbs.
- Hitch Height: 22″
- Hitch Weight (Empty): 300 lbs.
- Jack: 7,000 or 12,000 lb Drop Leg
- Payload Capacity: 12,756 lbs.
- Ply: 10 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 16″ E Range
20' Heavy Duty C&E w/ 2-7000 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 7720E, 7720M
- Overall Length: 24′
- Overall Width: 102″
- Axles: 2-7000 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 8-65 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 16″
- Curb Weight: 2,800 lbs.
- Deck Height: 26″
- Deck Length: 20′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel
- GVWR: 14,000 lbs.
- Hitch Height: 22″
- Hitch Weight (Empty): 300 lbs.
- Jack: 7,000 or 12,000 lb Drop Leg
- Payload Capacity: 12,600 lbs.
- Ply: 10 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 16″ E Range
22' Heavy Duty C&E w/ 2-7000 lbs. Axles
Specifications:
Available in: Express, Excursion
Model #s: 7722E, 7722M
- Overall Length: 26′
- Overall Width: 102″
- Axles: 2-7000 lb.
- Ball Size: 2 5/16″
- Between Fenders: 82″
- Bolt Pattern: 8-65 Bolt
- Brakes: Both Axles
- Coupler: 2 5/16″
- Crossmember: 3″ Channel
- Crossmember Spacing: 16″
- Curb Weight: 3,166 lbs.
- Deck Height: 26″
- Deck Length: 22′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- Frame & Hitch: 6″ Channel (8″
- Frame)
- GVWR: 14,000 lbs.
- Hitch Height: 22″
- Hitch Weight (Empty): 300 lbs.
- Jack: 7,000 or 12,000 lb Drop Leg
- Payload Capacity: 12,234 lbs.
- Ply: 10 Ply
- Slide in Ramps: 12″ x 60″
- Tires: 16″ E Range
