5' x 8' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 5X8SSE
- Overall Length: 11′ 8″
- Overall Width: 79″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 60″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 705 lbs
- Deck Height: 18″
- Deck Length: 8′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2990 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 66 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2584 lbs
- Ply: 6
- Tires: 205/75R15C
5' x 10' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 5X10SSE
- Overall Length: 13′ 8″
- Overall Width: 79″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 60″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 798 lbs
- Deck Height: 18″
- Deck Length: 10′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2990 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 73 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2491 lbs
- Ply: 6
- Tires: 205/75R15C
6' x 10' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 6X10SSE
- Overall Length: 13′ 8″
- Overall Width: 91″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 72″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 882 lbs
- Deck Height: 18″
- Deck Length: 10′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2990 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 79 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2407 lbs
- Ply: 6
- Tires: 205/75R15C
6' x 12' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 6X12SSE
- Overall Length: 15′ 8″
- Overall Width: 91″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 72″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 970 lbs
- Deck Height: 14″
- Deck Length: 12′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2990 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 97 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2319 lbs
- Ply: 6
- Tires: 205/75R15C
76 inches x 12' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 65X12SSE
- Overall Length: 15′ 8″
- Overall Width: 95″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 76″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 992 lbs
- Deck Height: 18″
- Deck Length: 12′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2990 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 110 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2297 lbs
- Ply: 6
- Tires: 205/75R15C
82 inches x 12' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 7X12SSE
- Overall Length: 15′ 8″
- Overall Width: 101″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 82″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 1036 lbs
- Deck Height: 18″
- Deck Length: 12′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2990 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 117 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2253 lbs
- Ply: 6
- Tires: 205/75R15C
82 inches 14' Solid Side w/ 3500 lb Axle
Specifications:
Available in: Express
Model #s: 7X14SSE
- Overall Length: 17′ 8″
- Overall Width: 101″
- Axles: 3500 lb
- Ball Size: 2″
- Bolt Pattern: 5 – 4.5 Bolt
- Box Width: 82″
- Box Height: 13″
- Brakes: Option
- Crossmember: 2″ x 2″ Angle
- Crossmember Spacing: 24″
- Curb Weight: 1102 lbs
- Deck Height: 18″
- Deck Length: 14′
- Electrical Hook-up: RV Plug
- Floor: 2″ Spruce
- GAWR: 3500 lbs
- GVWR: 2900 lbs
- Hitch Height: 14″
- Hitch Size: 3″ Channel
- Hitch Weight (Empty): 139 lbs
- Jack: 2000 lb A-frame
- Payload Capacity: 2187 lbs
- Ply: 6
- Tires: 205/75R15C
